Specification
200Ah 12.8V • 2.56kWh
100Ah 12.8V • 1.28kWh
Battery & Energy
Battery Type
LiFePO₄
LiFePO₄
Energy Capacity
2.56kWh
1.28kWh
Nominal Voltage
12.8V
12.8V
Operating Voltage
11.2–14.4V
11.2–14.4V
Current & Power
Recommended Charge / Discharge Current
120A
≤100A
Maximum Charge / Discharge Current
200A
150A
Recommended Charge / Discharge Power
1,500W
≤1,250W
Maximum Charge / Discharge Power
1,500W
1,875W
Depth of Discharge
≥95%
≥95%
Scalability & Communication
Parallel Connection
Up to 16 units
(40.96kWh)
Up to 16 units
(20.48kWh)
Series Connection
Up to 4 units
Up to 4 units
Communication
CAN2.0 / RS485
Wi-Fi / Bluetooth
RS485 / CAN
Performance & Protection
Protection Rating
IP21
IP21
Cycle Life
≥6,000 cycles
≥6,000 cycles
Charging Temperature
0–55°C
0–55°C
Discharging Temperature
-20–55°C
-20–55°C
Display
LED
LED
Installation
Floor-Mounted
Floor-Mounted
Protection
Smart BMS + Fuse
Smart BMS + Fuse
Warranty & Physical
Warranty
5 Years
5 Years
Net Weight
15.5kg
10kg
Gross Weight
18.5kg
12kg
Product Dimensions
329 × 248 × 199mm
295 × 201 × 199mm
Package Dimensions
391 × 310 × 257mm
357 × 263 × 261mm

Compare the Felicity Solar 12V Lithium Batteries

Choose the battery capacity that best matches your solar, inverter or backup power requirements.

FELICITY LiFePO₄ LITHIUM BATTERY 100Ah 12.8V FELICITY LiFePO₄ LITHIUM BATTERY 200Ah 12.8V
Feature 100Ah 200Ah
Nominal Voltage 12.8V 12.8V
Capacity 100Ah 200Ah
Energy 1.28kWh 2.56kWh
Chemistry LiFePO₄ LiFePO₄
BMS Built-in Smart BMS Built-in Smart BMS
Cycle Life 6000+ Cycles 6000+ Cycles
Warranty 5 Years 5 Years
Best For Smaller systems Higher energy requirements

Ideal for a Wide Range of Applications

Reliable lithium battery storage for homes, solar systems, businesses and mobile or remote power applications.

🏠 Home Backup Power
☀️ Solar Power Systems
🏢 Small Businesses & Offices
🚐 Caravans, 4x4 & Outdoor Use
📡 Remote Sites & Telecoms
FELICITY LiFePO₄ LITHIUM BATTERY SMART BMS

Advanced LiFePO₄ Technology for Greater Safety and Performance

Felicity Solar lithium batteries use Lithium Iron Phosphate (LiFePO₄) technology together with an intelligent Battery Management System (BMS).

LiFePO₄ chemistry provides excellent cycle life, efficient energy storage and dependable performance for solar, inverter and backup applications.

The integrated Smart BMS helps monitor and protect the battery during operation, providing an additional layer of protection for your energy storage system.

Built-In Battery Protection

Smart BMS protection helps safeguard the battery during everyday operation.

⚡
Overcharge
Protection
🔋
Over-discharge
Protection
🌡
Temperature
Protection
✓
Short Circuit
Protection

Ready to Upgrade Your Energy Storage?

Choose between the Felicity Solar 100Ah and 200Ah 12V LiFePO₄ lithium batteries above and find the right capacity for your solar, inverter or backup power system.
